Low Voltage Hybrid Energy Storage Inverter 10 Kw 10Kva MPPT PV Inverters For House Energy Storage
Payment :
T/T, L/C, Western UnionShipping Port :
ShanghaiParallel :
6 UnitsMonitoring :
WifiMax Power :
10000WOutput Voltage :
380VWarranty :
5 YearsCertificate :
CECommunication :
BMS (RS485)Protection :
IP20Order MOQ :
1Type :
Hybrid AC/DC InverterItem No. :
Xihe-10KLP3-EUXihe-10KLP3-EU high-quality inverter system outputs pure sine wave AC power, ensure reliable long-term operation at rated capacity, features an industrial design with a modern aesthetic, is easy to install and use, incorporates exclusive Li-ion battery BMS dual activation, offers remote monitoring of operating parameters, boasts advanced MPPT with up to 99.9% efficiency, provides comprehensive security from hardware to software, has multiple safety approvals, supports various types of batteries, and includes support for Li-ion battery BMS communication.
MODEL |
Xihe-10KLP3-EU
|
INVERTER
|
|
Rated Output Power
|
10,000W
|
Max.Peak Power
|
20,000W
|
Rated Output Voltage
|
230Vac, single-phase / three-phase, be paralleled
|
Load Capacity of Motors
|
6HP
|
Rated AC Frequency
|
50Hz/60Hz
|
Waveform
|
Pure Sine Wave
|
Switch Time
|
10ms(typical)
|
Parallel Capacity
|
1~6 units
|
Output Mode
|
O-grid (default)/Hybrid
|
BATTERY
|
|
Battery Type
|
Lead-acid/Li-ion/User defined
|
Rated Battery Voltage
|
48V
|
Voltage Range
|
40~60Vdc
|
Max.MPPT Charging Current
|
200A
|
Max.Mains/Generator Charging Current
|
120A
|
Max.Hybrid Charging Current
|
200A
|
PV INPUT
|
|
Num. of MPPT Trackers
|
2
|
Max.PV Array Power
|
5,500W + 5,500W
|
Max.Input Current
|
22A + 22A
|
MPPT Voltage Range
MAINS / GENERATOR INPUT
|
125~425Vdc |
Max.Voltage of Open Circuit
|
500Vdc + 500Vdc
|
MPPT Voltage Range
|
90~275Vac
|
Frequency Range
|
50/60Hz
|
Bypass Overload Current
|
63A
|
EFFICIENCY
|
|
MPPT Tracking Efficiency
|
99.9%
|
Max. Battery Inverter Efficiency
|
92%
|
GENERAL
|
|
Dimensions
|
620*445*130mm
|
Weight
|
27kg
|
Protection Grade
|
IP20, indoor onIy
|
Operating Temperature Range
|
-10~55℃, >45℃ derated
|
Noise
|
≤60dB
|
Cooling Method
|
Internal Fan
|
COMMUNICATION
|
|
Embedded Interfaces
|
RS485 / USB / Dry contact
|
External Modules (Optional)
|
Wi-Fi / GPRS
|
CERTIFICATION
|
|
Safety
|
IEC62109-1, IEC62109-2
|
EMC
|
EN61000-6-1, EN61000-6-3, FCC 15 class B
|
RoHS
|
Yes
|
![]() |
Our solar inverters are equipped with advanced technology to convert the direct current (DC) generated by your solar panels into alternating current (AC) to power your home or business. With their high conversion efficiency and smart power management features, our solar inverters ensure you get the most out of your solar system. |
In addition to superior performance, our solar inverters are designed with user convenience in mind. Its user-friendly interface and monitoring features make it easy to track the performance of your solar power system and make adjustments as needed. With built-in safety features and rugged construction, you can trust that our solar inverters will provide you with years of reliable, trouble-free operation. We offer a variety of shipping methods, including air, sea and ground, allowing you to choose the option that best suits your needs. This flexibility ensures you can transport your goods in the most efficient and cost-effective way. |
![]() |
