Sail Solar Factory Wholesale 30KW with MPPT Solar Hybrid Inverter for Solar Energy System

With ingress protection to IP65, 30kW is suitable for use both in outdoor applications and indoor environments where atmospheric moisture and dust are present, 30kW also offers a dual Ac input power source compatible with generator power to guarantee uninterruptible power. lt allows parallel operation up to 4 units for power expansion.

Specification

MODEL	Helios-30KLP3-EU
Maximum Pv Input Power	40000 W
Rated Output Power	30000 W
Maximum Charging Power	30000 W
PV INPUT (DC)
Maximum DC Voltage	720 VDC/ 1000 VDC
Start-up Voltage / Initial Feeding Voltage	320 VDC / 350 VDC
MPP Voltage Range	350 VDC ~ 900 VDC
Number of MPP Trackers / Maximum Input Current	3 / A:26A, B:26A, C:32A, D:26A
Number of Strings Per MPP Tracker	A:2, B:2, C:2
GRID OUTPUT (AC)
Nominal Output Voltage	230VAC(P-N)/400VAC(P-P)
Output Voltage Range	184 - 265 VAC per phase
Nominal Output Current	43.5 A  per phase
AC INPUT
AC Start-up Voltage / Auto Restart Voltage	120 - 140 VAC / 180 VAC per phase
Acceptable Input Voltage Range	170 - 280 VAC per phase
Maximum AC Input Current	50 A
BATTERY MODE OUTPUT (AC)
Nominal Output Voltage	230VAC(P-N)/400VAC(P-P)
Efficiency (DC to AC)	97%
BATTERY & CHARGER
Battery Voltage Range	500~900VDC
Maximum Solar Charging Current	50 A
Norminal Output Voltage	230VAC(P-N)/400VAC(P-P)
Efficiency (DC to AC)	97%
PHYSICAL
Size, D x W x H (mm)	255 x 660 x 750
Net Weight (kgs)	73
INTERFACE
Intelligent Slot	Optional SNMP and MODBUS
Communication Port	RS-232, USB, RS-485, Dry Contact, CAN, Wi-Fi, Bluetooth
ENVIRONMENT
Humidity	0 ~ 100% RH
Operating Temperature	-25°C to 60°C(>45℃ De-rating)
PROTECTION & CERTIFICA TE
Safety	IEC/EN 61000, IEC/EN 62920, EN62477
Protection Grade	IP65
Grid Connection Standard	NRS097-2-1:2017, VDE-AR-N4105, G99, IEC 61683, IEC 61727, IEC 62116

Application

Sail Solar Helios Hybrid 30KW is the single best 3-phase inverter we offer at the moment with 230VAC(P-N)/400VAC(P-P) output and it is designed mainly for industrial application with a DC nominal base voltage of 720V.  Unlike traditional industrial size UPS which relies mainly on grid power during normal operation and battery for backup, the Hybrid 30KW comes integrated with solar input which allows smart energy management by utilizing solar, battery and utility powers.  Similar to all of our hybrid-line inverters (grid feed capable), the Hybrid 30KW can also send any excess solar power to grid.

Helios 30kW Three Phase Hybrid solar Inverter is suitable for the household photovoltaic energy storage system. DC power generated by solar panels is stored in the battery through the inverter. When electricity is needed, it is first supplied by solar panels. If the light intensity cannot support the operation of solar panels, the inverter will convert the DC power of the battery into a single-phase power for home load. If the battery power is not enough, it can be quickly switched to power grid to supply power. With a power output of 30KW, this inverter is suitable for powering large buildings, factories, or even small communities. It is designed to be highly efficient, with a conversion efficiency of up to 98%, which helps to maximize the use of solar energy and reduce energy costs.
