Home Split Phase Hybrid Solar Inverter 6Kw 6Kva Energy Storage Inverters With Parallel Function
Category:
Still deciding? Get samples first, Contact US !
Product details
Product Introduction:
Embrace the future of energy management with the Home Split Phase Hybrid Solar Inverter 6Kw 6Kva, a cornerstone of quality home solar battery storage from China. This state-of-the-art inverter boasts a robust IP65 waterproof and dustproof design, ensuring it can withstand the rigors of outdoor installation. With the capability to support multiple input & output options, including Split Phase 208/240Vac or Single Phase 230Vac, it caters to a wide range of residential power needs. The inclusion of a built-in AC coupling function and WiFi for mobile monitoring via an app reflects the commitment to user convenience and smart home integration, hallmarks of quality home solar battery storage from China.
The Helios-6KLV-US split phase hybrid inverter power management system also stands out for its versatility, accepting a second input power source that is compatible with generators, and offering optional external CT sensors for achieving 100% self-consumption. The inverter’s built-in communication port for BMS (RS485) ensures seamless integration with advanced Lithium Battery Manufacturer from China products, while the user-adjustable charging current and voltage provide customization for optimal energy storage performance. Moreover, the support for parallel operation up to 6 units makes it an scalable solution for expanding energy needs, reinforcing its status as a premium offering in quality home solar battery storage from China.
Helios-6KLV-US split phase hybrid inverter power management system features IP65 waterproof and dustproof design, supports multiple input & output options (Split Phase 208/240Vac or Single Phase 230Vac). It includes built-in AC coupling function and WiFi for mobile monitoring via an app, accepts a second input power source compatible with generators and offers optional external CT sensors for 100% self-consumption. In addition, it has a built-in communication port for BMS (RS485), allows user-adjustable charging current and voltage, and supports parallel operation up to 6 units.
Specification
|
MODEL |
Helios-6KLV-US
|
|
Maximum Pv Input Power |
7500 W
|
|
Rated Output Power |
6000VA/6000W
|
|
Maximum Charging Power |
6000 W
|
|
PV INPUT (DC)
|
|
|
Maximum DC Voltage
|
600 VDC
|
|
Start-up Voltage / Initial Feeding Voltage
|
120VDC / 160 VDC
|
|
MPP Voltage Range
|
120 VDC ~ 550 VDC
|
|
Number of MPP Trackers / Maximum Input Current
|
2 / 15A
|
|
GRID OUTPUT (AC)
|
|
|
Nominal Output Voltage
|
110 VAC (P-N) / 220 VAC (P-P)
|
|
Output Voltage Range
|
97-132VAC(P-N) / 194VAC-264VAC(P-P)
|
|
Nominal Output Current
|
27.3 A per phase
|
| Power Factor |
0.9 lag to 0.9 lead |
|
AC INPUT
|
|
|
AC Start-up Voltage / Auto Restart Voltage
|
85VAC(P-N), 170VAC(P-P) / 90VAC(P-N), 180VAC(P-P)
|
|
Acceptable Input Voltage Range
|
85 - 140 VAC (P-N)/ 170 - 280 VAC (P-P)
|
|
Frequency Range
|
50 Hz/60 Hz (Auto sensing)
|
|
Maximum AC Input Current
|
30 A per phase
|
|
BATTERY MODE OUTPUT (AC)
|
|
|
Nominal Output Voltage
|
110 VAC (P-N) / 220 VAC (P-P)
|
|
Efficiency (DC to AC)
|
91%
|
|
BATTERY & CHARGER
|
|
|
Nominal DC Voltage
|
42-62 VDC
|
|
Maximum Solar Charging Current
|
120 A
|
| Maximum AC Charging Current |
120 A |
| Maximum Charging Current |
120 A |
|
PHYSICAL
|
|
|
Size, D x W x H (mm)
|
215.5 x 515 x 700
|
|
Net Weight (kgs)
|
41
|
|
INTERFACE
|
|
|
Parallel Function
|
Parallel Function
|
| Communication Port |
RS232, RS485, WI-FI, USB
|
|
ENVIRONMENT
|
|
|
Protection Degree
|
IP 65
|
|
Operating Temperature
|
-25°C to 60°C (>45°C derating)
|
Application
 |
With ingress protect of IP65, Helios-6KLV-US split -phase hybrid solar inverter is fully protected dust, airborne particles whilst and water jets which makes it suitable for use both in the indoor and harsh outdoor environment. It supports multiple input & output split phase 208/240vac. The solar inverter is also offering a second terminal for the users choice as a generator input or a programmable output. |
|
This cutting-edge 6kw inverter is a multifunctional hybrid solar inverter, capable of supporting even the most robust home power systems with a rated power of 6000W and the ability to handle PV arrays of up to 7500W. This high-tech inverter is easily installed, and comes equipped with an in-depth LCD touch screen interface for enhanced monitoring and a smoother user experience, as well as 2 MPPT inputs.
|
|
After-Sales Service
● " 7/24 " After-Sales Support
● 7 days a week, 24 hours a day: Ready to respond and solve problems immediately—Sail Solar's commitment to worry-free after-sales service.
● Service Email: info@sailsolaress.com
Service Process
01 |
Submit Service Requests Submit your service requests at any time via email, online customer service, or mobile app. |
02 |
Rapid Response Our service team will immediately respond to your requests and communicate the details of the issue with you. |
03 |
On-Site Service or Remote Support Depending on the nature of the problem, provide on-site service or remote technical support. |
04 |
Problem Resolution Our goal is to completely resolve your issue within 24 hours. |
05 |
Follow-Up After the problem is resolved, our team will continue to follow up to ensure your satisfaction with the service results. |
